General Purpose - Gerber Platinum Application Code = GP Gerber takes the guesswork out of choosing the correct bit. The application code is etched into the shank of the bit, along with the part number for easy identification.
Materials: Gerber Platinum series is a high performance tool for use with Hard and Soft Plastic, Hard and Soft Woods, Wood and Plastic Composites.
Aluminum & Wood Application Code = AW Gerber takes the guesswork out of choosing the correct bit. The application code is etched into the shank of the bit, along with the part number for easy identification.
PCUT BLADE PICTURES PCUT series plotter blades Technical data in the overview: - Cut media up to 0.25mm thick - Diameter: 1.5mm (0.08")/Length: 23mm (0.91") - Available in 30, 45 and 60 degree, 0.25mm offset - material: 89-90%Wc/10-11%Co - hardens: 91, 5HRA Rockwell - breaking strength:4000-4200N/mm2 - 5pk per box.
MIMAKI BLADE PICTURES MIMAKI series plotter blades Technical data in the overview: - Cutting media up to 0.25mm thick - Diameter: 1.5mm (0.08")/Length: 20mm (0.91") - Available in 30, 45 and 60 degree, 0.25mm offset - material: 89-90%Wc/10-11%Co - hardens: 91, 5HRA Rockwell - breaking strength:4000-4200N/mm2 - 5pk per box.
ROLAND BLADE PICTURES Roland series plotter blades Technical data in the overview: - Cutting media up to 0.25mm thick - Diameter: 2mm (0.08")/Length: 23mm (0.91") - Available in 30, 45 and 60 degree, 0.25mm offset - material: 89-90%Wc/10-11%Co - hardens: 91, 5HRA Rockwell - breaking strength:4000-4200N/mm2 - 5pk per box.
GRAPHTEC BLADE PICTURES Graphtec (CB09/CB15) series plotter blades Technical data in the overview: - Cut media up to 0.25mm thick (CB09)/ 1.50mm thick (CB15) - CB09 Diameter 0.9mm (0.04")/Length: 18mm (0.71") - CB15 Diameter 1.5mm (0.06”)/Length 18mm (0.71") - Available in 45 and 60 degree (CB09)/ 30, 45 and 60 degree (CB15), 0.25mm offset. - material: 89-90%Wc/10-11%Co - hardens: 91, 5HRA Rockwell - breaking strength:4000-4200N/mm2 - 5pk per box.
